Design & Drafting

DGH uses the latest 3D drafting technology. We can come to site and measure existing plant and structure in order to assist you with your drafting requirements.

Design & Drafting Services

We can complete drawings to any level you require

  • Conceptual
  • Client Review
  • Tender
  • Construction
  • Shop Detail
  • As Built

We can see to your:

  • Design of Structural, Mechanical and Piping Equipment
  • Equipment layouts
  • Reverse Engineer
  • 3rd Party Certification

Programmes we use:

  • Auto CAD
  • Inventor
  • Solid Works
  • Sheet and Plate

More Services

DGH Engineering is a leading engineering company, with 250+ employees, operating in and around Mackay, Central Queensland, Emerald, Townsville and Proserpine. DGH Engineering have workshop facilities in Mackay and Emerald with offices in both Proserpine and Townsville.
